NET, etc.ĬMT’s Manufacturing Test plugin is available to integrate the VNA into your production test system.A Network Analyzer is an instrument that measures the network parameters of electrical networks. Test Automation programming in LabView, Python, MATLAB.Markers with marker search tools and marker math, various conversion algorithms, and limit tests for pass/fail criteria, etc.16 independent channels with up to 16 traces each.Fixture simulation (embedding/de-embedding).Linear/logarithmic sweeps with multiple trace formats.The C1220 VNAs come with all the software features engineers have come to expect, at no additional cost. The add-on option for ISO17025/Z540-1 Accredited, Traceable Calibration Certificate and Uncertainties is available and needs to be specified at time of order.
VNAs and ACMs are delivered with factory calibration certificates containing no data. S2 software can be installed on multiple computers that share the use of the analyzer measurement module.
The VNA can be integrated into production test system via Manufacturing Test plug-in. Auxiliary Board Option is available on all Cobalt VNAs at the time of order (factory-installed) or as an add-on at a later date.Ĭ1220 VNA includes an RF measurement module and S2 software application which runs on Windows or Linux operating system on a PC, laptop, tablet, or x86 board computer connecting to the measurement hardware via USB interface. (14 kg), can be used in the laboratory and in production testing, without requiring a lot of space. This “full rack” vector network analyzer with dimensions of 16.9″ x 17.3″ x 5.5″ (430 x 440 x 140 mm) and a weight of just 31 lbs. C1220 Vector Network Analyzer delivers industry-leading dynamic range and sweep speed, with all the features engineers have come to expect included standard in our software.
